Description
CUMMINS 4BTA3.9-G Diesel Engine for Generator Set
CUMMINS 4BTA3.9-G Diesel Engine for Generator Set
The diesel engine has the highest thermal efficiency (engine efficiency) of any practical internal or external combustion engine due to its very high expansion ratio and inherent lean burn which enables heat dissipation by the excess air. A small efficiency loss is also avoided compared to two-stroke non-direct-injection gasoline engines since unburned fuel is not present at valve overlap and therefore no fuel goes directly from the intake/injection to the exhaust. Low-speed diesel engines (as used in ships and other applications where overall engine weight is relatively unimportant) can have a thermal efficiency that exceeds 50%.
| General of CUMMINS 4BTA3.9-G Diesel Engine for Generator Set | |
| Cylinder | In-line 4 |
| Compression Ration | 16.5:1 |
| Displacement | 3.9L |
| Fuel Injection Pump | A |
| Performance Data of CUMMINS 4BTA3.9-G Diesel Engine for Generator Set | |
| Rated Speed | 1500r/min (1800r/min) |
| Rated Power | 50KW (60KW) |
| Standby Power | 55KW |
| Genset Matching Power | 40KW |
| Steady Speed Droop | ≤1%(Electrical Governor) |
| Attachment(Power Pickup) equipment of CUMMINS 4BTA3.9-G Diesel Engine for Generator Set | |
| Attachment equipment can be offered according to customer's requirements. For sufficiently unleashing engine performance, whole engine attachmets from our company, evaluated by Dongfeng Cummins Engine Company, be recommended. | |
Type
Model
Rated
Power/Speed (Kw/RPM)
PeakTorque/Speed
(kW/rpm)
B3.9
cummins 4BT3.9-C80 engine for industry
60/2000
330/1500
cummins 4BT3.9-C100 engine for industry
75/2400
330/1500
cummins 4BT3.9-C105 engine for industry
77/2800
330/1500
cummins 4BTA3.9-C80 engine for industry
60/2200
350/1500
cummins 4BTA3.9-C100 engine for industry
74/2200
410/1500
cummins 4BTA3.9-C110 engine for industry
82/2200
460/1400
cummins 4BTA3.9-C120 engine for industry
90/2400
480/1500
cummins 4BTA3.9-C125 engine for industry
93/2200
475/1500
cummins 4BTA3.9-C130 engine for industry
97/2500
475/1500
cummins 4BTAA3.9-C80 engine for industry
60/2200
370/1300
cummins 4BTAA3.9-C100 engine for industry
74/2200
400/1500
cummins 4BTAA3.9-C110 engine for industry
82/2200
480/1400
cummins 4BTAA3.9-C115 engine for industry
85/2200
530/1400
cummins 4BTAA3.9-C115 engine for industry
85/2200
525/1300
cummins 4BTAA3.9-C125 engine for industry
93/2200
475/1500
cummins 4BTAA3.9-C130 engine for industry
97/2500
510/1400
B5.9(6BT)
cummins 6BT5.9-C115 engine for industry
85/2000
430/1500
cummins 6BT5.9-C120 engine for industry
87/2200
436/1500
cummins 6BT5.9-C125 engine for industry
92/2400
425/1500
cummins 6BT5.9-C130 engine for industry
97/2200
560/1500
cummins 6BT5.9-C135 engine for industry
100/2000
570/1500
cummins 6BT5.9-C135 engine for industry
100/1900
590/1500
cummins 6BT5.9-C135 engine for industry
100/2200
560/1500
cummins 6BT5.9-C145 engine for industry
106/2100
580/1500
cummins 6BT5.9-C150 engine for industry
110/2300
560/1500
cummins 6BT5.9-C150 engine for industry
112/2500
565/1500
cummins 6BT5.9-C150 engine for industry
110/2200
580/1500
cummins 6BT5.9-C150 engine for industry
112/2400
580/1500
B5.9(6BTA)
cummins 6BTA5.9-C150 engine for industry
112/1800
630/1400
cummins 6BTA5.9-C150 engine for industry
112/2200
655/1500
cummins 6BTA5.9-C155 engine for industry
114/2000
625/1500
cummins 6BTA5.9-C165 engine for industry
123/2200
694/1500
cummins 6BTA5.9-C170 engine for industry
125/2300
630/1400
cummins 6BTA5.9-C170(excavator) engine for
industry
125/2000
710/1300
cummins 6BTA5.9-C170(excavator) engine for
industry
125/2000
730/1300
cummins 6BTA5.9-C175 engine for industry
128/2100
680/1500
cummins 6BTA5.9-C180 engine for industry
132/2200
750/1300
cummins 6BTA5.9-C180 engine for industry
132/2500
630/1500
cummins 6BTAA5.9-C130 engine for industry
97/2200
580/1500
cummins 6BTAA5.9-C150 engine for industry
110/1950
718/1200
cummins 6BTAA5.9-C150 engine for industry
110/1950
706/1200
cummins 6BTAA5.9-C160 engine for industry
118/2200
670/1500
cummins 6BTAA5.9-C180 engine for industry
132/2200
770/1500
cummins 6BTAA5.9-C190 engine for industry
142/2200
As a leading manufacturer and supplier in China, we are specialized in complete engine and spare parts. Such as crankshaft, camshaft, con rod, cylinder head, cylinder block, cylinder liner, piston, piston ring, engine valve, engine bearing, oil nozzle, oil seal, oil pump, fuel pump, water pump, turbocharger, and so on
our products have exported many countrys .We are also the supplier for China DEUTZ/KHD,DONGFENG, CUMMINS,FAW,JAC,FOTON,CAMC, C&C,HOWO,ISUZU and LOVOL as well as MTU, KKK Germany
We also supply the china products which are made by joint venture with international engine and engine parts ,for example Elring, Bosch, Payen, Federal-mogul, TP, Holset, S.Valeo, Garrett, Borg-Warner, KKK, ZF, Eaton, Fuller, GKN, Thomson products which made in China under strict quality control and international quality standards.
We aim to be a top class supplier for worldwide OEM and aftermarket!
hope build good business relationship with all company which is do business in this field.
|
